Overview

Basic Info.

Model NO.	EV charger
Location	Public Use
Number of Charging Interfaces	One Pile with Multiple Charges
Start Mode	RFID Authentic
Charge Method	Quick Charge
Efficiency	Mini 95%
IP Class	IP54
Output Power	160kw
Input Voltage	380V
Type	Fast EV Charging Station
Certification	CE, ISO
Warranty	12 Months
Transport Package	Wooden Case
Trademark	TONHE
Origin	China
HS Code	8504409999
Production Capacity	100 Sets / Month

Packaging & Delivery

Package Size130.00cm * 70.00cm * 70.00cm Package Gross Weight58.000kg

Product Description

Tonhe is a high technology enterprise specialized in innovation of technology, product and management in the power electronics industry, and R & D, manufacturing ,sales, operation and service of EV charger module&rapid charger point and related products , providing customers with system solution for the energy sector.Tonhe was established in 1998 and got listed in 2015 with stock code 300491.

Tonhe has automatic production line with full automation in the previous production steps, and semi-automation in assembly and testing. Technological design and work fixture are designed and developed by the process technology department, ensuring product quality.

St. Petersburg Charging Station

Moscow Bus Station

Minsk Railway Station

Used in ship enviroment in Tailand

Product Description

Specification	Model	TH-AHTH-DC120-CC002
AC Nomal Input	Phases/Lins	3 phase+neutral+PE
	Voltage	400VAC±10%
	Frequency	50Hz±10%
	Connector	CCS
Output	Power	120KW
	Volatge	CCS:200-750VDC
	Cable Lenth	5m
	Cable Type	Charging cable and connecter permanently attached to EVSE (liquid cooled)
Electrial Parameter	Power Factor	≥0.99,≥ 0.96 (Full Load)
	THD Value	≤5%
	Stable Voltage Accuracy	≤±0.5%
	Stable Current Accuracy	≤±1%
	Efficiency	≥95% at nominal output power
Structure Design	Housing Material	Galvanized steel
	Installation Method	Vertical installation of ground
	LED Indicator	10 inches with 720 x 480 pixels TFT LCD Screen, user interface with touch screen or keypad.Toughened unbreakable glass to be used for display screen
	ON-OFF (Start-Stop) Switches	Mandatory
	Emergency Stop Button	Mushroom headed type
	Payment Method	RFID CARD /Phone APP with backend
Communication	Charegr v.s. Backend	Ethernet, Wi-Fi and 2G/3G/4G
	Communication Protocal	OCPP1.6
Environmental in dex	Working Temperature	-20ºC-+65ºC
	Storage Temperature	-40ºC-+65ºC
	Working Altitude	≤2000M
	Atmospheric pressure intensity	80 kpa to 110 kpa
	Application Site	Indoor/Outdoor
	Cooling Method	Forced air cool
Security Protection	Multiple Protection	Over Current, Under Current, Over Voltage, Residual Current, Surge Protection, Short Circuit, Earth Fault at input and output, Input Phase reversal, Emergency Shut-down with alarm, over temperature, Protection against electric shock.
	Warranty	3 years
Package Information	Product Dimension	550*850*1950(W*D*H)
	Net Weight	256KG
	External Packing	Wooden case
General Requirements
	Energy Transfer Mode	Conductive
	Charging Mode	CCS 2.0 - mode 4 - DC fast charging
	Reliability and Serviceability	Modularity, self-diagnostic features, fault codes and easy serviceability in the field
System Structure
	Regulation Method	Regulated DC EV Charging Station with combination of CVC or CCC but not simultaneously
	Isolation	Each output isolated from each other with proper insulation
	Power Supply	DC EV charging station connected to AC mains
	Charge control communication	Communicate by digital and analog signals
	Interface inter-operability	Inter-operable with any EV supporting CCS (for each gun respectively)
	Operator	Operated by a trained person or EV owner
Input Requirements
	Input Supply Failure Backup	Battery backup for minimum 1 hour for control system and billing unit, to enable activities such as billing, to be provided
Output Requirements
	No. of Outputs	2
	Output Connectors	2 output connectors
	Output Connector Compatibility	CCS: IEC 61851-23/24, IEC 62196-3, DIN 70121.
Mechanical Requirements
	Mechanical Stability	Shall not be damaged by mechanical impact as defined in IEC 61851-1
	Mechanical Impact	Shall not be damaged by mechanical impact as defined in IEC 61851-1
User Interface and Display Requirements
	Visual	Visual Indicators:Error indication, Presence of input supply indication, State of Charge process indication. Voice notifications:Voice Notifications: Related to start and stop of charging session in English / Nepali
	Support Language	English, with provision for additional regional languages
	Display Messages	EVSE should display appropriate messages for user during the various charging states like:-Vehicle plugged in / Vehicle plugged out'-Duration since start of charge and kWh consumed'-User authorization status'-Fault Conditions-Metering Information: Consumption Units
Performance Requirements
	DC Output Voltage and Current Tolerance	DC Output current regulation in Constant Current Charging (CCC); ±2.5 A for the requirement below 50 A, and ±5% of the required value for 50 A or more DC Output voltage regulation in constant voltage charging (CVC);
	Control delay of charging current in CCC	DC output current demand response time1 s Ramp up rate: 20 A/s or more.Ramp Down rate: 100 A/s or more
	Descending rate of charging current	EVSE should be able to reduce DC current with the descending rate of 100 A/s or more
	Periodic and random deviation(Current ripple)	DC Output current ripple limit of EVSE:1.5 A below 10 Hz, 6 A below 5 kHz, 9A below 150 kHz
	Periodic and random deviation(Volatge ripple)	Max. Ripple voltage ±5 V. Max slew rate ±20 V/ms
Billing Requirements
	Software Solution	CMS and USER APP
	Billing	Grid Responsive metering
